The new S5’s one-piece bar and stem is a big part of the bike’s increase in aerodynamic performance, but aerodynamic improvements are limited if the bike doesn’t fit you perfectly.
Sizes: 48cm, 51cm, 54cm, 56cm, 58cm, 61cm
Fork: Cervélo All-Carbon, Bayonet S5 Fork
1-piece Handlebar/Stem: Cervélo HB19 Carbon
Handlebar Sizing:
Size 48 - 36cm
Size 51 - 38cm
Size 54 - 40cm
Size 56 - 40cm
Size 58 - 40cm
Size 61 - 40cm
Stem Sizing:
Size 48 - 80mm
Size 51 - 90mm
Size 54 - 100mm
Size 56 - 100mm
Size 58 - 110mm
Size 61 - 120mm
Seatpost: Cervélo SP34 Carbon
Seatpost Sizing:
Size 48 - 0mm
Size 51 - 0mm
Size 54 - 0mm
Size 56 - 0mm
Size 58 - 15mm
Size 61 - 15mm
Saddle: Selle Italia NOVUS BOOST EVO SuperFlow Ti
Bottom Bracket: SRAM DUB Ceramic, BBright
Headset: FSA IS2 1-1/8, 36° x 45° / 1-3/8, 36° x 45°
Front Thru Axle: Cervélo Aero Thru Axle Front, M12x1.5mm, 122mm length
Rear Thru Axle: Cervélo Aero Thru Axle Rear, M12x1.0mm, 169mm length
Front Wheel: Reserve 57TA, DT Swiss 240, 12x100mm, 24H, centerlock, tubeless compatible
Rear Wheel: Reserve 64TA, DT Swiss 240, 12x142mm, XDR freehub, 24H, centerlock, tubeless compatible
Tires: Vittoria Corsa Pro TLR G2.0 700x29c
Shifter/Brake Levers: SRAM Force AXS E1
Crankset: SRAM Force AXS E1, 50/37T, DUB, with power meter
Crank Sizing:
Size 48 - 165mm
Size 51 - 165mm
Size 54 - 170mm
Size 56 - 170mm
Size 58 - 172.5mm
Size 61 - 172.5mm
Chain: SRAM Force E1
Cassette: SRAM Force E1, 10-33T, 12-Speed
Front Derailleur: SRAM Force AXS E1
Rear Derailleur: SRAM Force AXS E1
Brake Rotors: SRAM Paceline Centerlock
Accessories: - Cervélo Front Computer/Accessory Mount 887
- Cervélo Rear Accessory Mount
Max Tire Width (Actual): 34mm
| 48 | 51 | 54 | 56 | 58 | 61 | |
|---|---|---|---|---|---|---|
| Reach | mm | 367 | 376 | 384 | 392 | 401 | 409 |
| Stack | mm | 496 | 519 | 542 | 565 | 588 | 608 |
| Head Tube Angle | 71° | 72° | 73° | 73.5° | 73.5° | 73.5 |
| Front Center | mm | 579 | 580 | 581 | 588 | 604 | 617 |
| Bottom Bracket Drop | mm | 74.5 | 74.5 | 72 | 72 | 69.5 | 69.5 |
| Head Tube Length | mm | 64 | 82 | 104 | 125 | 152 | 173 |
| Top Tube Length | mm | 520 | 535 | 550 | 565 | 581 | 595 |
| Seat Tube Angle | 73° | 73° | 73° | 73° | 73° | 73 |
| Standover Height | mm | 712 | 734 | 758 | 781 | 804 | 822 |
| Trail | mm | 55.6 | 55.6 | 55.6 | 55.6 | 55.6 | 55.6 |
| Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
| Fork Offset | mm | 58.5 | 52.5 | 46.5 | 43.5 | 43.5 | 43.5 |
| Wheelbase | mm | 973 | 974 | 975 | 982 | 999 | 1013 |
| Chainstay Length | mm | 405 | 405 | 405 | 405 | 405 | 405 |
How do I determine what bike size I need?
The age-old question, isn’t it? There are many factors that go into bicycle sizing and fit, particularly for high-performance bikes. Without being able to measure you and see you on a bike, precise fit information is difficult to supply. It’s also not unusual for someone to be able to ride two different sizes depending on their goals, flexibility, and fit tolerance. That said, we have some fantastic retailers, and we’d encourage you to go start a conversation with them about what you want from your new bike. You can find the retailer closest to you on our.
