The ALL NEW SCOTT Addict 20 was designed from the ground up with those longer days in mind. With geometry that is less focused on racing and more on enduring, this bike is yearning to eat up some miles!
| XXS/47 | XS/49 | S/52 | M/54 | L/56 | XL/58 | XXL/61 | ||
| A | HEAD TUBE ANGLE | 70.5 ° | 71.0 ° | 72.0 ° | 72.5 ° | 73.0 ° | 73.3 ° | 73.3 ° |
| B | HEAD TUBE LENGTH | 3.7 IN | 4.1 IN | 4.9 IN | 5.7 IN | 6.5 IN | 7.3 IN | 8.1 IN |
| C | TOP TUBE HORIZONTAL | 20.3 IN | 20.7 IN | 21.3 IN | 21.9 IN | 22.4 IN | 23.0 IN | 23.6 IN |
| D | STANDOVER HEIGHT | 28.8 IN | 29.4 IN | 30.5 IN | 31.1 IN | 32.0 IN | 32.9 IN | 33.4 IN |
| E | BB OFFSET | -2.8 IN | -2.8 IN | -2.8 IN | -2.8 IN | -2.8 IN | -2.8 IN | -2.8 IN |
| F | BB HEIGHT | 10.8 IN | 10.8 IN | 10.8 IN | 10.8 IN | 10.8 IN | 10.8 IN | 10.8 IN |
| G | WHEEL BASE | 39.2 IN | 39.5 IN | 39.6 IN | 39.8 IN | 40.0 IN | 40.3 IN | 40.8 IN |
| H | BB CENTER TO TOPTUBE CENTER | 16.3 IN | 17.1 IN | 18.3 IN | 19.1 IN | 19.9 IN | 20.7 IN | 21.3 IN |
| I | BB CENTER TO TOP OF SEATTUBE | 17.9 IN | 18.7 IN | 19.9 IN | 20.7 IN | 21.5 IN | 22.2 IN | 22.8 IN |
| J | SEAT ANGLE | 75.0 ° | 75.0 ° | 74.5 ° | 74.0 ° | 73.5 ° | 73.1 ° | 73.0 ° |
| K | CHAINSTAY | 16.5 IN | 16.5 IN | 16.5 IN | 16.5 IN | 16.5 IN | 16.5 IN | 16.5 IN |
| L | REACH | 14.8 IN | 15.1 IN | 15.2 IN | 15.4 IN | 15.5 IN | 15.7 IN | 16.0 IN |
| M | STACK | 20.4 IN | 20.8 IN | 21.7 IN | 22.5 IN | 23.4 IN | 24.2 IN | 24.9 IN |
| N | STEM LENGTH | 2.9 IN | 3.3 IN | 3.7 IN | 4.1 IN | 4.1 IN | 4.4 IN | 4.4 IN |
